■ Table of output terminal functions 2
Function
No.
Code Function Action
23 PALN Inversion of pre-alarm Inversion of PAL setting
24 UC Small-current detection ON: The output current is equal to or less than
H set value for H set time.
OFF: The output current is equal to or larger than
H set value + 10%.
25 UCN Inversion of small-current detection Inversion of UC setting
26 HFL Significant failure ON: QEC,QEN,QV,G,
GGR ,GVP,GRJQ,GTT-
,QJ,WR,GH,WE,
GV[R ,GRJ)
OFF: Failure other than the above
27 HFLN Inversion of significant failure Inversion of HFL setting
28 LFL Insignificant failure ON: (QE-,QR-,QJ,QN-)
OFF: Failure other than the above
29 LFLN Inversion of insignificant failure Inversion of LFL setting
30 RDY1 Ready for operation (including ST/RUN) ON: Ready for operation (ST and RUN are also
ON)
OFF: Others
31 RDY1N Inversion of ready for operation (including
ST/RUN) Inversion of RDY1 setting
32 RDY2 Ready for operation (excluding ST/RUN) ON: Ready for operation (ST and RUN are not
ON)
OFF: Others
33 RDY2N Inversion of ready for operation (excluding ST/RUN) Inversion of RDY2
34 FCVIB Frequency VIB selection ON: VIB selected as frequency command
OFF: Terminal other than VIB selected as
frequency command
35 FCVIBN Inversion of frequency VIB selection Inversion of FCVIB
36 FLR Fault signal (put out also at the time of a retry) ON: When inverter trips or retries
OFF: When inverter does not trip or retry
37 FLRN Inversion of failure signal (put out also at the time
of a retry) Inversion of FLR
38 OUT0 Specified data output 1 ON: Specified data from remote control FA50:
BIT0= 1
OFF: Specified data from remote control FA50:
BIT0= 0
39 OUT0N Inversion of specified data output 1 Inversion of OUT0 setting
42 COT Cumulative operation time alarm ON: Cumulative operation time is equal to or
longer than H
OFF: Cumulative operation time is shorter than
H
43 COTN Inversion of cumulative operation time alarm Inversion of COT
44 LTA Parts replacement alarm ON: Calculation for parts replacement time is
equal to or longer than the preset time
ON: Calculation for parts replancement time is
shorter than the preset time
45 LTAN Inversion of replacement alarm Inversion of LTA
48 LI1 F terminal input signal ON: The signal input to F terminal is ON
OFF: The signal input to F terminal is OFF
49 LI1N Inversion of F terminal input signal Inversion of LI1
50 LI2 R terminal input signal ON: The signal input to R terminal is ON
OFF: The signal input to R terminal is OFF
51 LI2N Inversion of R terminal input signal Inversion of LI2
52 PIDF Signal in accordance of frequency command (VIA) ON: Frequency commanded by HOQF or
H and that by VIA show the same
value.
OFF: Frequency commanded by HOQF or
H and that by VIA show different
values.
