E6581381
F-79
6
+ The following are available as common serial optional units:
• USB communication conversion unit (Model: USB001Z)
Communication cable (Model: CAB0011 (1m), CAB0013 (3m), CAB0015 (5m))
• Internal LonWorks ® communication circuit board (Model: ILU007Z)
• Internal BACnet ® communication circuit board (Model: BCN002Z)
• Internal Metasys ® N2 communication circuit board (Model: MTS002Z)
• Internal Siemens APOGEE TM FLN communication circuit board (Model: APG002Z)
These internal products require no interconnect cables, because of built-in type.
■ Communication function parameters (Common serial options)
The data transfer speed, parity type, inverter number, and communication error trip time can be set/edited by
operation panel operation or communication function.
Title Function Adjustment range Default setting
H Communication rate
0: 9600bps
1: 19200bps
1
H Parity
0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1
H Inverter number 0-247 0
H Communication error trip time
0: Disabled (*)
1-100 (s)
0
H Communication waiting time
0.00: Regular communication
0.01-2.00 (s)
0.00
H
Setting of master and slave
for communication between
inverters
0: Slave (0 Hz command issued in
case the master inverter fails)
1: Slave (Operation continued in
case the master inverter fails)
2: Slave (Emergency stop tripping
in case the master inverter fails)
3: Master (transmission of
frequency commands)
4: Master (transmission of output
frequency signals)
0
H
Communication command point 1
setting
0-100 (%) 0
H
Communication command point 1
frequency
0-200.0 (Hz) 0.0
H
Communication command point 2
setting
0-100 (%) 100
H
Communication command point 2
frequency
0.0-200.0 (Hz)
50.0 (WP type)
60.0 (WN type)
H
Selection of communication
protocol
0: Toshiba inverter protocol
1: ModbusRTU protocol
2: Metasys N2 protocol
3: APOGEE FLN protocol
4: BAC-net protocol
0
