E6581381
K-8
11
• Torque boost parameters 1
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: Auto-tuning disabled
1: Application of individual settings of
H (after execution: 0)
H 0400 Auto-tuning - -
2: Auto-tuning enabled
(after execution: 0)
0
H 0401 Slip frequency
gain % 1/1 0-150 50
H 0402 Automatic torque
boost value % 0.1/0.1 0.0-30.0 * 1
H 0415 Motor rated
current A 0.1/0.1 0.1-200.0 * 1
H 0416 Motor no-load
current % 1/1 10-100 * 1
H 0417 Motor rated speed min-1 1/1 100-15000 * 1
H 0418 Speed control
response
coefficient - 1/1 1-150 40
H 0419 Speed control
stability coefficient - 1/1 1-100 20
5.10
6.15.1
*1 : Default values vary depending on the capacity. ⇒ See the table of page K-14.
• Input/output parameters 2
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H 0470 VIA input bias - - 0-255 128
H 0471 VIA input gain - - 0-255 148
H 0472 VIB input bias - - 0-255 128
H
0473 VIB input gain - - 0-255 148
6.5.4
• Torque boost parameters 2
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
H 0480 Exciting current
coefficient % 1/1 100-130 100 5.10
6.15.2
H
0481 Power supply
compensation filter - 1 0-9999 0 6.17.16
H
0482 Inhibitor filter - 1 0-9999 442
H
0483 Inhibitor gain - 0.1 0.0-300.0 100.0
H
0485 Stall prevention
control coefficient 1 - 1/1 10-250 100 5.10
6.15.2
H 0492 Stall prevention
control coefficient 2 - 1/1 50-150 100
H 0494 Motor adjustment
coefficient - 1/1 0-200 * 1
H 0495 Maximum voltage
adjustment
coefficient % 1/1 90-120 104
