High-performance Embedded Workshop 17. Using the Debugger
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
366
Options
Right-clicking displays a pop-up menu containing available options.
A basic operation is allocated to the toolbar.
The Toolbar display and Customize toolbar options are also included in the pop-up menu opened by right-clicking on
the toolbar.
Pop-up Menu Option Toolbar Button Macro Recording Description
Auto Update Marks the selected variable with a bold R and updates the
variable in real-time.
Auto Update All Marks all variables with bold Rs and updates all variables in
real-time.
Delete Auto Update Marks the selected variable with an outlined R and cancels
real-time update.
Delete Auto Update All Marks all variables with outlined Rs and cancels real-time
update.
Update Interval *1 - Sets an update interval.
Start
Recording Opens the Recording Settings dialog box and starts
recording the history of updating of values Record Update
Value
Stop
Recording Stops recording the history of updating of values.
Add Watch Launches the Add Watch dialog box, allowing the user to enter
a variable or expression to be watched.
Edit Name Launches the Edit Name dialog box, allowing the user to
change the watch item's name.
Edit Value Launches the Edit Value dialog box, allowing the user to
change the variable's value.
Set Scope - Sets the scope for the selected symbol.
Delete Removes the variable indicated by the text cursor from the
Watch window.
Delete All Removes all the variables from the Watch window.
Hexadecimal Displays in hexadecimal.
Decimal Displays in decimal.
Octal Displays in octal.
Radix
Binary Displays in binary.
Copy - Places a copy of the highlighted text into the Windows®
clipboard.
Save As - Saves the currently displayed contents.
Go To Memory - Opens a Memory window for the address.
Toolbar display - - Shows or hides the toolbar.
Customize toolbar - - Customizes toolbar buttons.
Notes:
*1. Available only when the debugger supports this function.
*2. Support for scope setting depends on the debugger in use and the debug format selected in the Debug Settings
dialog box.
(2) Adding a watch item
You can add watch items to the Watch window.
To add a watch item to a Watch window
Select either of the following ways.
• Drag a watch item from the Editor or Disassembly window and drop it into the Watch window.
• Use Instant Watch in the Editor or Disassembly (in source mode) window.
