High-performance Embedded Workshop
17. Using the Debugger
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
361
Displays the same-name functions or member functions and their detailed information.
Name
Displays the names of the functions
Select Function Name
Address Displays the addresses of the functions
Displays the function to be set and their detailed information.
Name
Displays the names of the functions
Set Function Name
Address Displays the addresses of the functions
Displays the number of the functions having the same name.
All Function
Displays the number of same-name functions or member functions.
Select Function
Displays the number of functions displayed in the Select Function Name
list box.
Counter
Set Function
Displays the number of functions displayed in the Set Function Name list
box.
(1) Selecting a function
Click the function you wish to select in the Select Function Name list box, and click the > button. You will see the
selected function in the Set Function Name list box. To select all functions in the Select Function Name list box, click
the > > button.
(2) Deselecting a function
Click the function you wish to deselect from the Set Function Name list box, and click the < button. To deselect all
functions, click the < < button. The deselected function(s) will be moved from the Set Function Name list box back to
the Select Function Name list box.
(3) Setting a function
Click the OK button to set the functions displayed in the Set Function Name list box. The functions are set and the
Select Function dialog box closes.
Click the Cancel button to close the dialog box without setting the functions.
17.17.2.4 Debugging an overlay program
Programs making use of the Overlay function can be debugged. This section explains the settings for using the
Overlay function.
(1) Displaying section group
When the Overlay function is used (i.e. when several section groups are assigned to the same address range), the
address ranges and section groups are displayed in the Overlay dialog box.
Open the Overlay dialog box by choosing [Debug -> Overlay]. This dialog box has two areas: the Address list box
and the Section Name list box.
