High-performance Embedded Workshop 13. Map
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
200
• The left pane shows the map list of the linkage editor.
- Nothing is displayed in this pane if there is no linkage list file (.map) output by the linkage editor.
- Selecting the root of the map list ("Linker map list") shows all symbol information in the right pane.
- Selecting a section in the map list only shows symbol information of the selected section in the right pane.
• The right pane shows the symbol information of the linkage editor.
- Clicking the column header sorts the listed items. When the window is first opened, the items are sorted by the
value of "Start Address".
- The "Attribute" column shows the symbol attribute.
Entry: Entry function
Function: Function name
Data: Variable name
None: Undefined (label or assembly symbol)
- The "Scope" column shows the scope attribute.
Global: Global symbol
Local: Local symbol
Window options
• Map list of the linkage editor (left pane)
Right-clicking displays a pop-up menu containing available options.
A basic operation is allocated to the toolbar.
The Toolbar display and Customize toolbar options are also included in the pop-up menu opened by right-clicking on
the toolbar.
Pop-up Menu Option Toolbar Button Function
Print Prints section tree view.
Toolbar display - Shows or hides the toolbar.
Customize toolbar - Customizes toolbar buttons.
• Symbol information of the linkage editor (right pane)
Right-clicking displays a pop-up menu containing available options.
A basic operation is allocated to the toolbar.
The Toolbar display and Customize toolbar options are also included in the pop-up menu opened by right-clicking on
the toolbar.
Pop-up Menu Option Toolbar Button Function
Find Finds a symbol.
Find Next Finds the next symbol that matches the search text.
Filter Filters the symbol information.
View source Views the source code for the address in the selected line.
Print Prints section list view.
