High-performance Embedded Workshop 15. Using the Macro-Recording Support Facility
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
226
15.5.2.12 Trace window
While a macro is being recorded, the following operation will be recorded into a macro file.
Target Operation Function
Acquisition pop-up menu option/toolbar
button Make setting in the dialog box opened by
clicking on the menu option or toolbar button Configures trace acquisition parameters.
15.5.2.13 Event window
While a macro is being recorded, the following operations will be recorded into a macro file.
Target Operation Function
Add pop-up menu option/toolbar button Adds the break point or break condition.
Edit pop-up menu option/toolbar button
Make setting in the dialog box opened by
clicking on the menu option or toolbar button Edits the break point or break condition.
Enable pop-up menu option/toolbar button Enables the selected break points or
break conditions.
Disable pop-up menu option/toolbar button Disables the selected break points or
break conditions.
Delete pop-up menu option/toolbar button Removes the selected break points or
break conditions.
Delete All pop-up menu option/toolbar button
Click on the menu option or toolbar button
Removes all break points or break
conditions.
15.5.2.14 Code Coverage window
While a macro is being recorded, the following operation will be recorded into a macro file.
Target Operation Function
Hardware Settings pop-up menu
option/toolbar button Make setting in the dialog box opened by
clicking on the menu option or toolbar button •
Allocates code coverage memory.
•
De-allocates code coverage memory.
15.5.2.15 Data Coverage window
While a macro is being recorded, the following operation will be recorded into a macro file.
Target Operation Function
Hardware Settings pop-up menu
option/toolbar button Make setting in the dialog box opened by
clicking on the menu option or toolbar button •
Allocates data coverage memory.
•
De-allocates data coverage memory.
15.5.2.16 Hardware Break dialog box
While a macro is being recorded, the following operation will be recorded into a macro file.
Target Operation Function
Apply button Click on the button Changes the hardware break conditions.
