High-performance Embedded Workshop 15. Using the Macro-Recording Support Facility
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
220
Go To Cursor pop-up menu option Runs program until the PC reaches cursor.
Set PC Here pop-up menu option Sets PC to the address at cursor.
S/W Breakpoints column Double-click on
the column Sets or clears a software breakpoint.
Go To Cursor pop-up menu option Sets or clears a software breakpoint.
Set PC Here pop-up menu option Enables or disables the current software breakpoint.
Toggle Breakpoint pop-up menu option Runs program until the PC reaches cursor.
Enable/Disable Breakpoint pop-up menu
option
Click on the
menu option
Sets PC to the address at cursor.
Mixed/disassembly
mode
S/W Breakpoints column Double-click on
the column Sets or clears a software breakpoint.
15.5.1.3 Disassembly window
While a macro is being recorded, the following operations will be recorded into a macro file.
Display Mode Target Operation Function
Toggle Breakpoint pop-up menu option Sets or clears a software breakpoint.
Enable/Disable Breakpoint pop-up menu
option Enables or disables the current software breakpoint.
Go To Cursor pop-up menu option Runs program until the PC reaches cursor.
Set PC Here pop-up menu option
Click on the
menu option
Sets PC to the address at cursor.
Source mode
S/W Breakpoints column Double-click on
the column Sets or clears a software breakpoint.
Go To Cursor pop-up menu option Sets or clears a software breakpoint.
Set PC Here pop-up menu option Enables or disables the current software breakpoint.
Toggle Breakpoint pop-up menu option Runs program until the PC reaches cursor.
Enable/Disable Breakpoint pop-up menu
option
Click on the
menu option
Sets PC to the address at cursor.
Mixed/disassembly
mode
S/W Breakpoints column Double-click on
the column Sets or clears a software breakpoint.
15.5.1.4 Register window
While a macro is being recorded, the following operations will be recorded into a macro file.
Target Operation Function
Edit pop-up menu option Make setting in the dialog box opened by clicking on the menu option
Flag register * Click on the flag register
In-place edit
Value
Make setting in a dialog box opened by double-clicking a value
Changes a register's content.
Note:
*. Support for this function depends on the debugger.
15.5.1.5 Memory window
While a macro is being recorded, the following operations will be recorded into a macro file.
Target Operation Function
Set Pop-up menu option/toolbar button Modifies memory contents.
Fill Pop-up menu option/toolbar button Fills a block of memory.
Move Pop-up menu option/toolbar button Moves a block of memory.
Compare Pop-up menu option/toolbar
button * Compares memory contents.
Save Pop-up menu option/toolbar button Saves memory to a file.
Load Pop-up menu option/toolbar button
Make setting in the dialog box opened
by clicking on the menu option or
toolbar button
Loads a memory area contents from a file.
