High-performance Embedded Workshop 13. Map
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
189
13. Map
Among the section settings of the linkage editor and the contents of the linkage list file output by the linkage editor,
information on sections and symbols are respectively shown. There are the following features.
Sections
- A tree view in the form of address – section group – section
- Assignment of sections can be changed by drag and drop
- You can add, modify, or delete addresses, section groups, and sections
- The source file for the address in the selected line can be opened in the editor window
- The contents can be printed out
Symbols
- Lists all symbol information or those for respective sections
- You can search for, filter, or sort (this function is not supported by the evaluation version) symbol information
- The source file for the address in the selected line can be opened in the editor window
- The contents can be printed out
• Supported toolchains
The toolchains included in the following compiler packages support the map function.
o C/C++ Compiler package for SuperH family V.7.1.03 and later
o C/C++ Compiler package for H8SX, H8S, and H8 family V.5.0.05 and later
o C Compiler package for M16C series V.5.42 Release 00 and later
o C Compiler package for M32C series V.5.41 Release 00 and later
o C Compiler package for R32C series V.1.01 Release 00 and later
• To view the information on sections and symbols
To view the information on sections and symbols, the following setting is required in advance:
1. Select [Build -> xxxxxx Standard Toolchain] to open the build options dialog box.
2. Select List for Category in the Link/Library tab.
3. Select the Generate list file checkbox. This allows output of information on sections.
4. Click the Enable all button. This allows output of information on symbols.
5. Select [Build -> Build].
