High-performance Embedded Workshop 9. Using Visual SourceSafe
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
169
To remove a directory mapping
1. Select [Tools -> Version Control -> Configure]. The Version Control Setup dialog box opens.
2. Select the Mapping tab.
3. Select the mapping to be removed from the list and then click the Remove button.
9.6 Adding Visual SourceSafe commands
In the Custom Commands tab of the Version Control Setup dialog box, you can add a menu defining a Visual
SourceSafe command not included in the version control submenu.
Selecting this menu executes the defined command. Output information on execution of this command will be shown in
the Version Control tab of the Output window.
This section introduces the definition of Properties command as an example.
• Execution control of version control commands
1. Select the Prompt before executing command checkbox.
2. Deselect the Run in DOS Window checkbox. (This is because the RCS commands must be input via the MS-
DOS prompt.)
3. Select the User forward-slash '/' as version control directory delimiter checkbox. (Visual SourceSafe uses
this format.)
For detail, see section 8.9, Controlling execution of a Version Control System.
• Setting up commands
1. Click the Add button. The Add Menu Option dialog box appears.
2. Enter "Properties" in Option and click the Add button. The Add Command dialog box appears.
