High-performance Embedded Workshop 13. Map
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
202
3. Select the Enable Filter checkbox. By default, this checkbox is not selected.
4. Select a column in Filter Column.
5. Select a filtering condition in Filter Item.
Filter Column Filter Item Function
Function Filter by functions
Data Filter by data symbols
Entry Filter by positions to start execution
Attribute (symbol attribute)
None Filter by other symbols (such as labels)
Global Filter by global symbols Scope (scope attribute)
Normal Filter by local symbols
Section (sections containing symbols) Section name Filter by section names
File (files containing symbols) File name Filter by file names
6. Clicking the Set All button selects the check boxes of all filtering conditions.
7. Clicking the Clear All button de-selects the check boxes of all filtering conditions.
8. Click OK.
Symbol information of the linkage editor shown in the right pane is filtered by the selected condition. For further
filtering by combining a different condition, select another column and then select a filtering condition in the column.
To disable filtering, de-select the Enable Filter checkbox in the Filter Symbol dialog box.
13.2.5 Viewing the source code for the address
The source file for the address in the selected line will be opened in the editor window.
To view the source code for the address
Select one of the following operations:
• Right-click on the symbol-list line in the right pane to open a pop-up menu. Then select View Source, OR
• Double-click on the symbol-list line in the right pane.
