High-performance Embedded Workshop 15. Using the Macro-Recording Support Facility
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
219
• Windows
While a macro is being recorded, operations made in the windows listed below will be recorded into a macro file. For
information on the types of recordable operations, see the descriptions of the respective windows.
Window Name Opened by
Projects tab of the Workspace window [View -> Workspace]
Editor Double-clicking on a file in the Projects tab of the workspace window
Disassembly [View -> Disassembly]
Register [View -> CPU -> Registers]
Memory [View -> CPU -> Memory]
IO [View -> CPU -> IO]
15.5.1.1 Projects tab of Workspace window
While a macro is being recorded, the following operations will be recorded into a macro file.
Target Operation Function
Workspace
Clean All Projects pop-up menu option
*1 Deletes intermediate and output
files from configurations in all
projects in this workspace.
Build pop-up menu option *1 Builds out of date project files.
Build All pop-up menu option *1 Builds project files, regardless of
whether the project files are out of
date.
Clean Current Project pop-up menu
option *1 Deletes intermediate and output
files from the current configuration
in this project.
Project
Set as Current Project pop-up menu
option Sets this project as the current
project.
Project file
Build pop-up menu option
*1 Builds a file.
Download all module pop-up menu
option
Click on the menu option
Loads all object (program) files.
Download
modules folder Download A New Module pop-up menu
option
Make setting in the dialog box opened
by clicking on the menu option *2
- Double-click on a download module
Download module pop-up menu option
Download module (debug data only)
pop-up menu option
Loads an object (program) file.
Unload module pop-up menu option
Click on the menu option
Unloads an object (program) file
from memory.
Download
module
Download A New Module pop-up menu
option Make setting in the dialog box opened
by clicking on the menu option *2 Loads an object (program) file.
Notes:
*1. Available only when there is a toolchain installed.
*2. Only options Offset, File format, Filename, Access size, and Perform memory verify during download can be
recorded; Download debug information only and Download automatically on target connection are not
recordable.
15.5.1.2 Editor window
While a macro is being recorded, the following operations will be recorded into a macro file.
Display Mode Target Operation Function
Build "" pop-up menu option Builds the selected file.
Toggle Breakpoint pop-up menu option Sets or clears a software breakpoint.
Source mode
Enable/Disable Breakpoint pop-up menu
option
Click on the
menu option
Enables or disables the current software breakpoint.
