Renesas REJ10J1837-0100 - Manual (Page 299)

High-performance Embedded Workshop 17. Using the Debugger
REJ10J1837-0100 Rev.1.00 Nov. 16, 2008
284
If the files are not full paths and are relative or short file names, they will automatically be searched for relative to the
download module directory.
Files that cannot be found after the initial search will be shown to you in the Locate Files dialog box.
However, you can choose not to open the Locate Files dialog box at downloading.
To prevent opening of the Locate Files dialog box at downloading
1. Select [Setup -> Options]. The Options dialog box will be displayed.
2. Select the Confirmation tab.
3. Select the Do not show Debug only workspace browse dialog on download checkbox. This checkbox is not
selected by default.
4. Click OK.
• Debuggers supporting the feature of showing a source tree
This feature is only supported by the debuggers that can create debug-only projects. The condition of the support,
however, depends on the debugger as shown below.
Debugger Condition of the Support
SuperH family emulator debugger
H8SX, H8S, H8 family emulator debugger The High-performance Embedded Workshop has become V.4.02 or later due to an
update.
M16C family emulator debugger The High-performance Embedded Workshop included in the product package is V.4.02
or later.
(1) Locating files
Files that cannot be found or do not exist after the initial search will be shown to the user in the Locate Files dialog box
(in the Files to find list).
