Adding a CS 1000 Release 5.0 Branch Office to a Branch Office with a previous software release
197
For further information on upgrading the IP Phone firmware, refer to IP
Line Fundamentals (NN43100-500). For information on upgrading and
reconfiguring the Signaling Server software, refer to Signaling Server
Installation and Commissioning (NN43001-312).
Upgrade the entire network to CS 1000 Release 5.0
To upgrade the entire network to CS 1000 Release 5.0:
Step
Action
1
At the main office:
a. Upgrade the Call Server software to CS 1000 Release 5.0.
b. Upgrade the main office Signaling Servers software to CS 1000
Release 5.0 with the Automatic Firmware Upgrade set.
c. Reconfigure the main office Signaling Server to configure the
NRS.
d. Upgrade the main office Voice Gateway Media Cards to CS 1000
Release 5.0.
2
At each existing CS 1000 4.0 or CS 1000 4.5 Branch Office:
a. Upgrade the Small System Controller to CP-PM Call Server and
MGC (CS 1000 Release 5.0).
b. Upgrade the MG 1000B Signaling Servers software to CS 1000
Release 5.0 with the Automatic Firmware Upgrade set.
c. Reconfigure the MG 1000B Signaling Servers to configure the
NRS.
d. Upgrade the MG 1000B Voice Gateway Media Cards to CS 1000
Release 5.0.
3
Execute the
umsUpgradeAll
command on the main office
Signaling Servers, or Voice Gateway Media Cards, if necessary.
4
Install the new CS 1000 Release 5.0 Branch Office as described in
"Implementation summary" (page 194)
.
—End—
