Page 150

150
Alternative Call Routing for Network Bandwidth Management
The printout for all configured zones appears as follows:
#
Alternate Routing Status
10
ENL
11
DIS
12
DIS
LD 117 - Obtain status for a Branch Office zone(s).
Command
Description
STAT ZBR
Show status of specified Branch Office zone, where:
zone = bandwidth zone
If you do not enter a value in the zone field, you obtain a printout of the status of all configured
Branch Office zones.
The printout for all configured Branch Office zones appears as follows:
#
State
Flags
Des
10
ENL
TIM
BVW
11
DIS
LOC ALT
TOR
12
DIS
ESA ALT
Des entries are codes you assign to each Branch Office for your own
records.
Element Manager diagnostics
Print zone Alternative Call Routing information
The print capability allows the following parameters to be viewed for each
zone:
•
enable/disable status of the Alternative Call Routing for NBWM feature
•
ALTPrefix digits
•
enable/disable status of the All Calls option
Procedure 5
Printing zone ALTPrefix
Step
Action
1
From the navigator, click System > Maintenance. The Maintenance
web page appears. (See
Figure 58 "System Maintenance web
.)
