Network using CDP only

119

Figure 47
Call flow for Scenario 3- calls to remote Branch Office (destination side)

1. Main office B determines that this is to a local Branch Office with prefix

225. The system transmits 225-53456 to the NRS. The NRS checks its
provisioning, and determines that this call goes to Branch Office B1.

2. The main office sends the call to 225-53456 to the Branch Office. The

Branch Office deletes the prefix and LSC, and rings set 3456.
