310 KAYENNE — User Manual
Section 3 — System Operation
Set All to None —Sets all Linked Sources to none (blank).
Set All to Current —Sets all Linked Sources to the currently selected Source
(including none if defined).
Store button—Allows the current source table to be stored (copied) to
another source table.
Configuring Source Tables
In the example in Figure 207 , Source Table 15 (Engineering ID) has been
configured with source substitutions using the Source Tables menu and
given the Source Table Name “Home Team”. This Source Table can now be
easily identified and assigned to one or many bus links in the Bus Links,
Links Setup menu (
Figure 205 ).
Figure 207. Source Tables
To add/rename a source table name:
Give a source table a descriptive Source Table Name or rename a source
table by touching the
Rename button ( Figure 205 ), entering the name into
the pop-up keyboard, and touching Enter .
Source List for
Linked Source
Column
