Configuration Options for AS2000 and ConnecT1 Plus
Access Manager 2000 User Manual 5 -99
Installed and Operational
This setting should be the same as the Installed and
Operational option setting for the associated CSU.
Save Configuration to DIU
To store the configuration from the database into the DIU, set the Save
configuration to DIU option to Y . If this option is set to N , any
updated changes are saved to the database but are not downloaded to the
DIU.
Connected CSU Shelf and Plug Numbers
Specify the AS2000 shelf number and plug-in module slot number of the
CSU associated with the selected DIU 2140. The shelf number can be
from 1 to 4. The plug-in module slot number can be from 1 to 13 for a
multiline shelf or 1 to 2 for a dual-line shelf.
Channel Assignment
Assign an available DS0 channel of the associated DS1 line to the DIU.
This number can be from 1 to 24.
This parameter also has an key associated with it so that you can
view the allocated channels. For additional information, see “Channel
Assignment” on page 5 -93.
Mode
To select the transmission mode of the DIU 2140, press in the
Mode field. The Select Mode screen will appear.
F8
F8
