DMD20/DMD50/DMD2050/DMD2050E/DMD1050/OM20 Remote Protocol Remote Operations
MN-DMDREMOTEOP Revision 9 1–71
Command Data (1 Byte)
<1> Descrambler Type 0 = None, 1 = IBS, 2 = V35 IESS, 3 = V35 CCITT, 4 =
V35 EFDATA, 5 = V35 FAIRCHILD, 6 = OM-73, 7 =
RS, 8 = RS EFDATA, 9 = TPC, 10 = DVB, 11 =
EDMAC, 12 = TPC and IBS, 13 = TPC and EDMAC, 14
= V35 ComStream, 15 = R11, 16 = Ebem Sync
Opcode: <2A0Fh>
Command a Demodulator’s Spectrum
Command Data (1 Byte)
<1> Spectrum 0 = Normal, 1 = Inverted
Opcode: <2A10h>
Command a Demodulator’s Buffer Size
Command Data (1 Byte)
<1> Buffer Size msec Indicates buffer size in msecs, 0 through 64
Opcode: <2A11h>
Command a Demodulator’s Buffer Clock
Command Data (7 Bytes)
<1> Active Buffer Clock
Source 0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI
<1> Number of Buffer
Clock Sources 1 – 5
<1> First Buffer Clock
Source 0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI, Each buffer clock source must be unique
<1> Second Buffer Clock
Source 0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI, Each buffer clock source must be unique
<1> Third Buffer Clock
Source
0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI, Each buffer clock source must be unique
<1> Forth Buffer Clock
Source
0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI, Each buffer clock source must be unique
<1> Fifth Buffer Clock
Source 0 = SCTE, 1 = SCT, 2 = EXT BNC, 3 = RX SAT, 4 =
EXT IDI, Each buffer clock source must be unique
Opcode: <2A12h>
Command a Demodulator’s Buffer Clock Polarity
Command Data (1 Byte)
<1> Buffer Clock Polarity 0 = Normal, 1 = Inverted
Opcode: <2A13h>
Command a Demodulator’s Insert Mode
Command Data (1 Byte)
<1> Insert Mode 0 = Disabled, 1 = T1-D4, 2 = T1-ESF, 3 = PCM-30, 4 =
PCM-30C, 5 = PCM-31, 6 = PCM-31C, 7 = SLC-96, 8 =
T1 D4 S, 9 = T1 ESF S
Opcode: <2A15h>
Command a Demodulator’s T1E1 Frame Source
Command Data (1 Byte)
<1> T1E1 Frame Source 0 = Internal, 1 = External, 2 = IDI/DDO Loopback
Opcode: <2A16h>
Command a Demodulator’s Satellite Framing
