MAXQ Family User’s Guide:
MAXQ2010 Supplement
20-5
20.2.9 LCD Display Register 6 (LCD6, M2[11h])
20.2.10 LCD Display Register 7 (LCD7, M2[12h])
20.2.11 LCD Display Register 8 (LCD8, M2[13h])
20.2.12 LCD Display Register 9 (LCD9, M2[14h])
20.2.13 LCD Display Register 10 (LCD10, M2[15h])
20.2.14 LCD Display Register 11 (LCD11, M2[16h])
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
