MAXQ Family User’s Guide:

MAXQ2010 Supplement

16-2

• Registers SPIB, I2CBUF, and ADDATA are not read, and their values are returned as 0000h.
The first byte output by this command is the value 144 (090h), which represents the number of peripheral register
words output. Table 16-1 lists the remaining 352 bytes output by this command.

Table 16-1. Output from DebugReadMap Command

x0

x1

x2

x3

x4

x5

x6

x7

x8

x9

xA

xB

xC

xD

xE

xF

0x

PO0

PO1

PO2

PO3

EIF0

EIE0

1x

PI0

PI1

PI2

PI3

EIES0

PWCN

2x

PD0

PD1

PD2

PD3

3x

RTRM

RCNT

RTSS

RTSH

RTSL

RSSA

RASH

RASL

4x

PO4

PO5

PO6

0000h

EIF1

EIE1

EIF2

EIE2

5x

PI4

PI5

PI6

EIES1

EIES2

SVM

6x

PD4

PD5

PD6

SPICN

SPICF

SPICK

7x

8x

MCNT

MA

MB

MC2

MC1

MC0

LCFG

9x

MC1R

MC0R

LCRA

LCD0

LCD1

LCD2

LCD3

LCD4

Ax

LCD5

LCD6

LCD7

LCD8

LCD9

LCD10

LCD11

LCD12

Bx

LCD13

LCD14

LCD15

LCD16

LCD17

LCD18

LCD19

LCD20

Cx

0000h

I2CST

I2CIE

SCON0

SBUF0

SCON1

SBUF1

Dx

SMD0

PR0

SMD1

PR1

I2CCN

I2CCK

I2CTO

I2CSLA

Ex

Fx

10x

TB0R

TB0C

TB1R

TB1C

TB2R

TB2C

ADST

ADADDR

11x

TB0CN

TB0V

TB1CN

TB1V

TB2CN

TB2V

ADCN

0000h

12x

AP

APC

PSF

IC

IMR

SC

IIR

CKCN WDCN

00

A[0]

A[1]

A[2]

13x

A[3]

A[4]

A[5]

A[6]

A[7]

A[8]

A[9]

A[10]

14x

A[11]

A[12]

A[13]

A[14]

A[15]

IP

SP+1

IV

15x

LC[0]

LC[1]

OFFS

DPC

GR

BP

DP[0]

DP[1]
