MAXQ Family User’s Guide:
MAXQ2010 Supplement
4-6
Table 4-4. System Clock Modes
FLLMD SWB PMME CD1 CD0 SYSTEM CLOCK SWITCHBACK
0 0 0 0 0 High-frequency clock/1 —
0 0 0 0 1 High-frequency clock/2 —
0 0 0 1 0 High-frequency clock/4 —
0 0 0 1 1 High-frequency clock/8 —
0 0 1 X X High-frequency clock/256 Not Active
0 1 1 X X High-frequency clock/256 Active
1 0 0 0 0 FLL clock/1 —
1 0 0 0 1 FLL clock/2 —
1 0 0 1 0 FLL clock/4 —
1 0 0 1 1 FLL clock/8 —
1 0 1 X X FLL clock/256 Not Active
1 1 1 X X FLL clock/256 Active
