MAXQ Family User’s Guide:
MAXQ2010 Supplement
6-14
6.1.30 External Interrupt Edge Select 2 Register (EIES2, M1[0Ch])
Each bit in this register controls the edge select mode for an external interrupt as follows:
0 = The external interrupt triggers on a rising (positive) edge.
1 = The external interrupt triggers on a negative (falling) edge.
Bit 7: Edge Select for External Interrupt 22 (IT22)
Bit 6: Edge Select for External Interrupt 21 (IT21)
Bit 5: Edge Select for External Interrupt 20 (IT20)
Bit 4: Edge Select for External Interrupt 19 (IT19)
Bit 3: Edge Select for External Interrupt 18 (IT18)
Bit 2: Edge Select for External Interrupt 17 (IT17)
Bit 1: Edge Select for External Interrupt 16 (IT16)
Bit 0: Edge Select for External Interrupt 15 (IT15)
6.2 GPIO and External Interrupt Code Examples
6.2.1 GPIO Example 1: Driving Outputs on Port 0
move PO0, #000h
; Set all outputs low
move PD0, #0FFh
; Set all P0 pins to output mode
6.2.2 GPIO Example 2: Receiving Inputs on Port 1
move PO1, #0FFh
; Set weak pullups ON on all pins
move PD1, #000h
; Set all P1 pins to input mode
nop
; Wait for external source to drive P1 pins
move Acc, PI1
; Get input values from P1 (will return FF if
; no other source drives the pins low)
Bit #
7
6
5
4
3
2
1
0
Name
IT22
IT21
IT20
IT19
IT18
IT17
IT16
IT15
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
