14.4 RTC Register Descriptions

Addresses of registers are given as “Mx[yy],” where x is the module number (from 0 to 15 decimal) and yy is the reg-
ister index (from 00h to 1Fh hexadecimal). Fields in the bit definition tables are defined as follows:
• Name: Symbolic names of bits or bit fields in this register.
• Reset: The value of each bit in this register following a standard reset. If this field reads “unchanged,” the given bit

is unaffected by standard reset. If this field reads “s,” the given bit does not have a fixed 0 or 1 reset value because
its value is determined by another internal state or external condition.

• POR: If present this field defines the value of each bit in this register following a power-on reset (as opposed to a

standard reset). Some bits are unaffected by standard resets and are set/cleared by POR only.

• Access: Bits can be read-only (r) or read/write (rw). Any special restrictions or conditions that could apply when

reading or writing this bit are detailed in the bit description.

14.4.1 RTC Trim Register (RTRM, M0[18h])

Bit 7: RTC Trim Sign Bit (TSGN). This register bit selects whether 32K clocks are inserted (TSGN = 1) or removed
(TSGN = 0).
Bits 6:4: Reserved. Read returns zero.
Bits 3:0: RTC Trim Calibration Register (TRM[3:0]). These register bits provide a binary value between 00h to 0Fh,
which is used for adjusting 32K clocks insertion/removal. At every 10-second interval, a number of 32K clocks equal to
the RTRM[3:0] numeric value x 8 is inserted/removed from the RTC counter depending on the TSGN sign bit.

14.4.2 RTC Control Register (RCNT, M0[19h])

Note 1: This register is reset by power-on reset only.
Note 2: Write to this register is ignored when WE = 0 or RCNT.BUSY = 1.

Note 1: Bits 0 and 13 are reset by power-on reset only.
Note 2: Bits 14, 12:4, and 2:1 are reset by any reset source.
Note 3: Bit 3 is set to a 1 on system reset.
Note 4: Bit 0 is only writable when WE = 1 and BUSY = 0.
Note 5: Bit 13 is only writable when RTCE = 0.
Note 6: Bits 9:6 and 2:1 are only writable when BUSY = 0.

Bit #

7

6

5

4

3

2

1

0

Name

TSGN

TRM

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Bit #

15

14

13

12

11

10

9

8

Name

WE

ACS

FT

SQE

Reset

0

1

0

0

0

0

0

0

Access

rw

rw

rw

rw

rw

rw

rw

rw

Bit #

7

6

5

4

3

2

1

0

Name

ALSF

ALDF

RDYE

RDY

BUSY

ASE

ADE

RTCE

Reset

0

0

0

0

0

0

0

0

Access

rw

rw

rw

rw

r

rw

rw

rw
