Table 5-2. Peripheral Register Bit Functions (continued)
Table 5-3. Peripheral Register Bit Reset Values
REG
BIT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TB0CN C/TB — — TBCS TBCR TBPS (3 bits) TFB EXFB TBOE DCEN EXENB TRB ETB
CP/
RLB
TB0V TB0V (16 bits)
TB1CN C/TB — — TBCS TBCR TBPS (3 bits) TFB EXFB TBOE DCEN EXENB TRB ETB
CP/
RLB
TB1V TB1V (16 bits)
TB2CN C/TB — — TBCS TBCR TBPS (3 bits) TFB EXFB TBOE DCEN EXENB TRB ETB
CP/
RLB
TB2V TB2V (16 bits)
ADCN — — — — ADINT (2 bits)
ADCLK
(2 bits)
IREF
EN
AD
CONT
AD
DAIE
AD
PMO
ADACQ (4 bits)
ADDATA ADDATA (16 bits)
REG
BIT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PO0 1 1 1 1 1 1 1 1
PO1 1 1 1 1 1 1 1 1
PO2 1 1 1 1 1 1 1 1
PO3 1 1 1 1 1 1 1 1
EIF0 0 0 0 0 0 0 0 0
EIE0 0 0 0 0 0 0 0 0
PI0 s s s s s s s s
PI1 s s s s s s s s
PI2 s s s s s s s s
PI3 s s s s s s s s
EIES0 0 0 0 0 0 0 0 0
PWCN 0 0 0 0 0 0 0 0 0 0 0 0 s s 0 0
PD0 0 0 0 0 0 0 0 0
PD1 0 0 0 0 0 0 0 0
PD2 0 0 0 0 0 0 0 0
PD3 0 0 0 0 0 0 0 0
RTRM 0 0 0 0 0 0 0 0
RCNT 0 0 0 0 0 0 0 0 0 0 0 0 s 0 0 s
RTSS s s s s s s s s
RTSH s s s s s s s s s s s s s s s s
RTSL s s s s s s s s s s s s s s s s
RSSA 0 0 0 0 0 0 0 0
RASH 0 0 0 0 0 0 0 0
RASL 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PO4 1 1 1 1 1 1 1 1
PO5 1 1 1 1 1 1 1 1
PO6 1 1 1 1 1 1 1 1
