MAXQ Family User’s Guide:
MAXQ2010 Supplement
2-9
2.8 Reset Conditions
There are four possible reset sources for the MAXQ2010. While in the reset state, the enabled system clock oscillator
continues running, but no code execution occurs. Once the reset condition has been removed or has completed, code
execution resumes at address 8000h for all reset types.
Table 2-2. Interrupt Sources and Control Bits (continued)
INTERRUPT
MODULE ENABLE BIT
LOCAL ENABLE BIT
INTERRUPT FLAG
External Interrupt 13 (P5.5)
IM1 (IMR.1)
EX13 (EIE1.5)
IE13 (EIF1.5)
External Interrupt 14 (P5.6)
IM1 (IMR.1)
EX14 (EIE1.6)
IE14 (EIF1.6)
External Interrupt 15 (P6.0)
IM1 (IMR.1)
EX15 (EIE2.0)
IE15 (EIF2.0)
External Interrupt 16 (P6.1)
IM1 (IMR.1)
EX16 (EIE2.1)
IE16 (EIF2.1)
External Interrupt 17 (P6.2)
IM1 (IMR.1)
EX17 (EIE2.2)
IE17 (EIF2.2)
External Interrupt 18 (P6.3)
IM1 (IMR.1)
EX18 (EIE2.3)
IE18 (EIF2.3)
External Interrupt 19 (P6.4)
IM1 (IMR.1)
EX19 (EIE2.4)
IE19 (EIF2.4)
External Interrupt 20 (P6.5)
IM1 (IMR.1)
EX20 (EIE2.5)
IE20 (EIF2.5)
External Interrupt 21 (P6.6)
IM1 (IMR.1)
EX21 (EIE2.6)
IE21 (EIF2.6)
External Interrupt 22 (P6.7)
IM1 (IMR.1)
EX22 (EIE2.7)
IE22 (EIF2.7)
Supply Voltage Monitor Interrupt
IM1 (IMR.1)
SVMIE (SVM.2)
SVMI (SVM.3)
SPI Mode Fault Interrupt
IM1 (IMR.1)
ESPII (SPICF.7)
MODF (SPICN.3)
SPI Write Collision Interrupt
IM1 (IMR.1)
ESPII (SPICF.7)
WCOL (SPICN.4)
SPI Receive Overrun Interrupt
IM1 (IMR.1)
ESPII (SPICF.7)
ROVR (SPICN.5)
SPI Transfer Complete Interrupt
IM1 (IMR.1)
ESPII (SPICF.7)
SPIC (SPICN.6)
I
2
C START Condition Interrupt
IM3 (IMR.3)
I2CSRI (I2CST.0)
I2CSRIE (I2CIE.0)
I
2
C Transmit Complete Interrupt
IM3 (IMR.3)
I2CTXI (I2CST.1)
I2CTXIE (I2CIE.1)
I
2
C Receive Ready Interrupt
IM3 (IMR.3)
I2CRXI (I2CST.2)
I2CRXIE (I2CIE.2)
I
2
C Clock Stretch Interrupt
IM3 (IMR.3)
I2CSTRI (I2CST.3)
I2CSTRIE (I2CIE.3)
I
2
C Timeout Interrupt
IM3 (IMR.3)
I2CTOI (I2CST.4)
I2CTOIE (I2CIE.4)
I
2
C Slave Address Match Interrupt
IM3 (IMR.3)
I2CAMI (I2CST.5)
I2CAMIE (I2CIE.5)
I
2
C Arbitration Loss Interrupt
IM3 (IMR.3)
I2CALI (I2CST.6)
I2CALIE (I2CIE.6)
I
2
C NACK Interrupt
IM3 (IMR.3)
I2CNACKI (I2CST.7)
I2CNACKIE (I2CIE.7)
I
2
C General Call Address Interrupt
IM3 (IMR.3)
I2CGCI (I2CST.8)
I2CGCIE (I2CIE.8)
I
2
C Receiver Overrun Interrupt
IM3 (IMR.3)
I2CROI (I2CST.9)
I2CROIE (I2CIE.9)
I
2
C STOP Condition Interrupt
IM3 (IMR.3)
I2CSPI (I2CST.11)
I2CSPIE (I2CIE.11)
Serial Port 0 Receive
IM3 (IMR.3)
ESI (SMD0.2)
RI (SCON0.0)
Serial Port 0 Transmit
IM3 (IMR.3)
ESI (SMD0.2)
TI (SCON0.1)
Serial Port 1 Receive
IM3 (IMR.3)
ESI (SMD1.2)
RI (SCON1.0)
Serial Port 1 Transmit
IM3 (IMR.3)
ESI (SMD1.2)
TI (SCON1.1)
ADC Data Available Interrupt
IM4 (IMR.4)
ADDAIE (ADCN.5)
ADDAI (ADST.5)
Type B Timer 0—External Trigger
IM4 (IMR.4)
EXFB (TB0CN.6)
ETB (TB0CN.1)
Type B Timer 0—Overflow
IM4 (IMR.4)
TFB (TB0CN.7)
ETB (TB0CN.1)
Type B Timer 1—External Trigger
IM4 (IMR.4)
EXFB (TB1CN.6)
ETB (TB1CN.1)
Type B Timer 1—Overflow
IM4 (IMR.4)
TFB (TB1CN.7)
ETB (TB1CN.1)
Type B Timer 2—External Trigger
IM4 (IMR.4)
EXFB (TB2CN.6)
ETB (TB2CN.1)
Type B Timer 2—Overflow
IM4 (IMR.4)
TFB (TB2CN.7)
ETB (TB2CN.1)
