MAXQ Family User’s Guide:

MAXQ2010 Supplement

6-2

Table 6-1. Port Pin Special and Alternate Functions (continued)

PORT PIN

FUNCTION TYPE

FUNCTION

ENABLED WHEN

P2.3

Special Analog

LCD Segment SEG19

DPE = 1 and PCF2 = 1

P2.4

Special Analog

LCD Segment SEG20

DPE = 1 and PCF2 = 1

P2.5

Special Analog

LCD Segment SEG21

DPE = 1 and PCF2 = 1

P2.6

Special Analog

LCD Segment SEG22

DPE = 1 and PCF2 = 1

P2.7

Special Analog

LCD Segment SEG23

DPE = 1 and PCF2 = 1

P3.0

Special Analog

LCD Segment SEG24

DPE = 1 and PCF3 = 1

P3.1

Special Analog

LCD Segment SEG25

DPE = 1 and PCF3 = 1

P3.2

Special Analog

LCD Segment SEG26

DPE = 1 and PCF3 = 1

P3.3

Special Analog

LCD Segment SEG27

DPE = 1 and PCF3 = 1

P3.4

Special Analog

LCD Segment SEG28

DPE = 1 and PCF3 = 1

P3.5

Special Analog

LCD Segment SEG29

DPE = 1 and PCF3 = 1

P3.6

Special Analog

LCD Segment SEG30

DPE = 1 and PCF3 = 1

P3.7

Special Analog

LCD Segment SEG31

DPE = 1 and PCF3 = 1

P4.0

Special Analog

LCD Segment SEG32

DPE = 1 and PCF4 = 1

P4.1

Special Analog

LCD Segment SEG33

DPE = 1 and PCF4 = 1

P4.2

Special Analog

LCD Segment SEG34

DPE = 1 and PCF4 = 1

P4.3

Special Analog

LCD Segment SEG35

DPE = 1 and PCF4 = 1

P4.4

Special Analog

LCD Segment SEG36

DPE = 1 and PCF4 = 1

P4.5

Special Analog

LCD Segment SEG37

DPE = 1 and PCF4 = 1

P4.6

Special Analog

LCD Segment SEG38

DPE = 1 and PCF4 = 1

P4.7

Special Analog

LCD Segment SEG39

DPE = 1 and PCF4 = 1

P5.0

Alternate

External Interrupt 8

(EIE1.0) EX8 = 1

P5.0

Alternate

Type B Timer 0 Input B

EXENB = 1

P5.0

Special

Type B Timer 0 Output B (Compare Output)

TBCR:TBCS<>00b
(overrides Serial 0 Data)

P5.0

Special

Serial Port 0 Data (Mode 0)

Mode 0: SBUF0 is written or REN is set to 1
(until serial transmission completes)

P5.0

Alternate

Serial Port 0 Receive (Modes 1/2/3)

Modes 1/2/3: REN = 1

P5.1

Alternate

External Interrupt 9

(EIE1.1) EX9 = 1

P5.1

Alternate

Type B Timer 0 Input A (Counter Input)

C/TB = 1

P5.1

Special

Type B Timer 0 Output A (Clock Output)

C/TB = 0 and TB0E = 1 (overrides serial
port 0 transmit/clock)

P5.1

Special

Serial Port 0 Transmit/Clock

Mode 0: REN set to 1 (until serial transmis-
sion completes)
Mode 1/2/3: SBUF0 is written (until serial
transmission completes)

P5.2

Alternate

External Interrupt 10

(EIE1.2) EX10 = 1

P5.2

Special

RTC Square-Wave Output

RTCE = 1 and SQE = 1

P5.3

Alternate

External Interrupt 11

(EIE1.3) EX11 = 1

P5.3

Alternate

SPI Slave-Select Input (SSEL)

SPIEN = 1 and MSTM = 0

P5.4

Alternate

External Interrupt 12

(EIE1.4) EX12 = 1

P5.4

Alternate

MOSI: SPI Slave Input (Slave Mode)

SPIEN = 1 and MSTM = 0

P5.4

Special

MOSI: SPI Master Output (Master Mode)

SPIEN = 1 and MSTM = 1

P5.5

Alternate

External Interrupt 13

(EIE1.5) EX13 = 1

P5.5

Alternate

SCLK: SPI Clock Input (Slave Mode)

SPIEN = 1 and MSTM = 0
