MAXQ Family User’s Guide:
MAXQ2010 Supplement
20-10
20.9 LCD Display Memory
The LCD0 to LCD20 registers provide 21 bytes of display memory. Depending on the duty cycle and package type,
not all display memory can be used by the LCD controller. Any display memory that is unused by the LCD controller
can be used for application purposes if desired. The following tables show the display memory mapping for different
duty cycle and package configurations.
Table 20-2. Approximate LCD Frame Frequencies (Hz) (continued)
Table 20-3. LCD Display Memory Map (Static)
FRM[3:0]
f
LCD
= 32,768Hz/2
f
LCD
= 19,531Hz (10MHz/512)
1, 1/2, 1/4
1/3
1, 1/2, 1/4
1/3
8
29
19
34
23
9
26
17
31
21
10
24
16
28
19
11
22
14
26
17
12
20
13
24
16
13
19
12
22
15
14
17
12
21
14
15
16
11
19
13
REGISTER
BIT 7
COM0
BIT 6
COM0
BIT 5
COM0
BIT 4
COM0
BIT 3
COM0
BIT 2
COM0
BIT 1
COM0
BIT 0
COM0
LCD0
SEG7
SEG6
SEG5
SEG4
SEG3
SEG2
SEG1
SEG0
LCD1
SEG15
SEG14
SEG13
SEG12
SEG11
SEG10
SEG9
SEG8
LCD2
SEG23
SEG22
SEG21
SEG20
SEG19
SEG18
SEG17
SEG16
LCD3
SEG31
SEG30
SEG29
SEG28
SEG27
SEG26
SEG25
SEG24
LCD4
SEG39
SEG38
SEG37
SEG36
SEG35
SEG34
SEG33
SEG32
LCD5
SEG42
SEG41
SEG40
LCD6
LCD7
LCD8
LCD9
LCD10
LCD11
LCD12
LCD13
LCD14
LCD15
LCD16
LCD17
LCD18
LCD19
LCD20
