4-17
Chapter 4 Function Settings
4
6
Press the ENT key after the value is set.
The input value is entered and the area display appears again.
Function Output Selection
Select either Focus, Area, or Difference to be output from the output terminal block on the
rear panel.
Setting Range
Any one of the following items is selectable for output. Refer to Section 6 I/O Terminals
on page 6-1 for the FUNCTION output terminals in details.
• Focus monitor
• Area check
• Difference check
■ Setting Method
1
Select the area to be set and press
the
ENT key.
2
Press the FUNC key four times.
3
Press the or key and set the output item.
PROG No.
PRINT
AREA DISP
ESC PROG
FUNC ENT
H
Z
FOCUS
2
1
A R E A POSITION
Selected item
The following items are displayed for
setting.
Focus monitor
Area check
Difference check
HI
HI
HI
4
Press the
ENT
key.
The input value is entered and the area
display appears again.
HI
GO
LO
