7-21
Chapter 7 RS-232C
7
■ Reading Environment Settings
It is possible to read all environment settings in detail.
Note: P-COPY, P-CLEAR, or L-INSPCT settings are not read with this command.
S A cr
LS
Command
Response
Binary data
S A , Data 0 Data 1 Data X Checksum range
Data 0 through data X (X=87)
The checksum need not be calculated for
simple upload and download
operations.
Checksum Checksum
■ Writing Environment Settings
Saved environment settings that were read with the read command (SA command) can
be written to the LS-7000 Series.
Note: P-COPY, P-CLEAR, or L-INSPCT settings are not read with this command.
Binary data
S B , Data 0 Data 1 Data X
S B cr
LS
Command
Response
Checksum range
Data 0 through data X (X=87)
The checksum need not be calculated for
simple upload and download
operations.
Checksum Checksum
Timing Chart
The following timing chart is for commands and responses.
Command Command
Response
t
Response
Period t varies with the command as shown below.
Measurement
control
command
t=Sampling period + 3 ms
(2) Program number selection t=9ms
(3) Commands other than (1) or (2) t=3ms
Setting change command t=17ms (40 ms for calibration)
Setting confirmation command t=3ms
Reading and writing whole settings t=35ms
(1) Measured value output under
timing control (Command L)
