4-54
Chapter 4 Function Settings
4
Option Settings
Settings, such as display unit and I/O terminal mode, are available on the LS-7000 Series.
Option Settings
The following option settings are available.
• Tolerance mode:
Sets the tolerance mode to use either reference values or
thresholds.
• Timing mode: Sets the timing input terminals for OUT1 and OUT2 respec-
tively.
• Unit: Changes the display unit of measured values.
• Minimum display unit: Changes the minimum display unit of measured values.
• I/O mode:
Changes the I/O connector mode to SUB from BCD or vice
versa.
Option setting
Make method settings while monitoring the sub display.
1
Press the PROG key.
PRINT
ESC PROG
FUNC ENT
2
Press the FUNC key five times.
“Option” appears on the screen. HI
GO
LO
