8-2
Chapter 8 Specifications
8
Specifications
Controller
Display type
Minimum display unit
Display range
Measuring position monitor
Tolerance comparator output display
Alarm output
5-level comparator output
Comparator waiting output
Strobe output
Timing input
Reset input
Auto zero input
Program selection input
Analog output
Timing input
Reset input
Auto zero input
RS-232C interface
Model
Number of connectable measuring heads
5-level comparator output
Comparator waiting output
Strobe output
Function output
BCD output
BCD selection output
BCD selection input
Electrical
rating ( ❈2)
Environment
resistance
Power supply voltage
Current consumption
Enclosure rating
Ambient temperature
Relative humidity
SUB
mode
( ❈1)
BCD
mode
( ❈1)
LS-7001
2 (interchangeable)
Main display 7-segment red LED (20.3 mm high)
Sub display 7-segment red LED (9.9 mm high) x 3
0.1µm to 100µm (7 selectable levels), 0.0000005 to 0.000 inch (4 selectable levels)
±0.9999995 to ±999.9999 inch (varies with the minimum display units, inch/mil selectable),
±99.99999~±9999.9mm (varies with the minimum display units, mm/µm selectable)
Red LED 7-level display
Green LED (GO), Red LED x 2 (HI, LO)
NPN open collector output (N.C.)
OUT1 NPN open collector output
OUT1 non-voltage input
Non-voltage input x 4
±10 V x 2 outputs
OUT2 NPN open collector output
Focus, area check, or difference selectable, NPN open collector output x 2
Measuring data output (sign + 7 digit) OUT1/OUT2 selectable, NPN open collector output
NPN open collector output
Non-voltage input
Out2 non-voltage input
Measurement data output and control I/O for printer
(Baud rate selectable up to 15200 bps)
Simultaneous measurement, area setting, calculation, averaging, calibration, 16
program memory, measurement, automatic zero, print-out, abnormal value elimination,
transparent object measurement and mutual interference prevention
24V DC ±10%
0.7A max
IP64 (panel surface only)
0 to +40°C (32 to 104°F), No freezing
35 to 85% RH, No condensation
Approx. 820 g Weight
Te
rminal b
loc
k
Displa
y
Connector I/O
Main functions
❈1: Select either the SUB or BCD mode.
❈2: AC power supply is available through the LS-S11 (AC Power Supply Stand).
The terminal block has a maximum open collector output of 100 mA (at 40 V max.) with a maximum residual
voltage of 1 V. The connector I/O has a maximum NPN open collector output of 30 mA (at 30 V max.) with a
maximum residual voltage of 1 V. The non-voltage input has a maximum rated ON voltage of 1 V and
maximum OFF current of 0.6 mA.
