6-6
Chapter 6 I/O Terminals
6
BCD Mode
Terminal number Cable color Signal name Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Brown
Red
Orange
Yellow
Green
Blue
Purple
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Purple
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Purple
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Purple
Gray
White
Black
COM2
BCD POLE
BCD DIGIT 7 (8)
BCD DIGIT 7 (4)
BCD DIGIT 7 (2)
BCD DIGIT 7 (1)
BCD DIGIT 6 (8)
BCD DIGIT 6 (4)
BCD DIGIT 6 (2)
BCD DIGIT 6 (1)
BCD DIGIT 5 (8)
BCD DIGIT 5 (4)
BCD DIGIT 5 (2)
BCD DIGIT 5 (1)
COM2
BCD DIGIT 4 (8)
BCD DIGIT 4 (4)
BCD DIGIT 4 (2)
BCD DIGIT 4 (1)
BCD DIGIT 3 (8)
BCD DIGIT 3 (4)
BCD DIGIT 3 (2)
BCD DIGIT 3 (1)
BCD DIGIT 2 (8)
BCD DIGIT 2 (4)
BCD DIGIT 2 (2)
BCD DIGIT 2 (1)
BCD DIGIT 1 (8)
BCD DIGIT 1 (4)
BCD DIGIT 1 (2)
BCD DIGIT 1 (1)
BCD INDICATE
OUT 1/2
OUT2 STROBE
COM2
BCD SELECT
OUT 1/2
OUT2 TIMING
OUT2 RESET
OUT2 ZERO
(Not used)
AREA1 FUNCTION
Connector I/O common
BCD output polarity
BCD output 7th digit
(Leftmost digit)
BCD output 6th digit
BCD output 5th digit
Connector I/O common
BCD output 4th digit
BCD output 3rd digit
BCD output 2nd digit
BCD output 1st digit
(Rightmost digit)
BCD output OUT number
selection output
OUT2 strobe output
Connector I/O common
BCD output OUT number
selection input
OUT2 timing input
OUT2 RESET input
OUT2 auto zero input
AREA1 function output
NPN open collector output
➾
See page 6-10
NPN open collector
output
➾
See page 6-10
NPN open collector
output
➾
See page 6-10
Non-voltage input
➾
See page 6-9
❈ Terminals 1, 8, and 37 share the COM2 signal in common.
❈ The cable colors correspond to OP-26505.
• The 0-V power supply, COM1, and COM2 signals are common
in voltage through a choke coil each. Check that there is no
potential difference between them.
• All unused terminals must be open. Do not connect any wires
to them, otherwise the LS-7000 Series may malfunction.
CAUTION
