viii
No.
Measured va
Measured va
between the r
and threshold
setting. (See pa
Press the
DISP
LS-7001 Operation Map
PROG No.
PRINT
ESC PROG
FUNC ENT
FOCUS
2
1
A R E A POSITION
Press the Up or Down key.
Program selection
PROG No.
Press the Up or Down key to
select the area.
AREA
Program Settings
Set item selection:
Set item cancellation:
Select the area (See page 3-4)
Entering set item:
Area, calibration, output, or option
setting:
Environment setting:
The selected area appears on the
AREA display.
POSITION monitor
FOCUS monitor
Press the key while pressing
the key.
Press the key and select the
item with key.
The POSITION monitor is lit according to the
position and size of the target.
The FOCUS monitor is lit according
to the distance between the
transmitter and receiver.
To make lit range changes, refer to
page 4-14.
Press the or key.
Press the key.
Press the key.
PROG
FUNC
ESC
ENT
PROG
FUNC
