4-13
Chapter 4 Function Settings
4
screen.
Measuring head No. 1
Measuring head No. 2
HI
HI
DIA (Diameter)
T-EDGE (Top edge)
B-EDGE (Bottom edge)
SEG (Segment)
HI
HI
HI
GO
LO
SEG (Segment) Setting
HI
GO
LO
Input the start edge (pitch) number.
The value must be smaller than the end
edge (pitch number).
Select the E or P
mode as desired.
The setting part
flashes.
Input the end edge
(pitch) number.
The value must be
larger than the start
edge (pitch) number.
Note: • The duplicated designation of an edge or pitch number will set the meas-
ured value to 0.
• If edges or pitches are designated in reverse order, negative measured
values will be obtained.
(1) Input the start edge (pitch) number.
PROG No AREA DISP
HOLD
ZERO
LO
Select the E or P mode
with these keys.
Press these keys
to set the value.
Press this key to set
the value to a positive
or negative one.
(2) Press the ENT key.
PROG No.
PRINT
AREA DISP
ESC PROG
FUNC ENT
H
Z
FOCUS
2
1
A R E A POSITION
