KEYENCE LS-7000 User Manual
Page 24
1-10
1
Chapter 1 Getting Started
LS-7030
Multi-purpose
Mounting Holes
A fixture for targets can
be attached.
Transmitter (T Head)
Emits light for
measurement.
Receiver (R Head)
Receives light from
the transmitter.
Cover Glass
TR Cables
Used to connect the
transmitter and receiver.
Extension Cable
Connected to the controller.
TR Base
Used to mount the
transmitter and receiver.
Mounting Holes
Used to mount the measuring head.
LS-7070
Multi-purpose
Mounting Holes
A fixture for targets can
be attached.
Cover Glass
Transmitter (T Head)
Emits light for
measurement.
Receiver (R Head)
Receives light from
the transmitter.
TR Cables
Used to connect the
transmitter and receiver.
Extension Cable
Connected to the controller.
TR Base
Used to mount the
transmitter and receiver.
Mounting Holes
Used to mount the measuring head.
