■ Output Settings
Area calculation (CALC)
OUT1 : A1 1.0
A2 OFF
OUT2 : A1 OFF
A2 1.0
Number of averaging times (AVE) 512
Measuring mode (MEA-MODE) NORMAL
Offset (OFFSET)
Threshold
(TOL)
Reference
value (DEV)
0.00000
+30.00000
0.00000
1000 μm/V
OFF
+10.5V
0.4ms
N.O.
0ms
Scaling at 10 V
(A-OUT+10)
Scaling at -10 V
(A-OUT-10)
Analog output setting: Analog
update mode (A-SET)
Analog output setting: Voltage for awaiting
result of measurement (A-CONT)
Comparator output setting:
Strobe output time (STOBE-T)
Comparator output setting:
Output logic (OUT-SET)
Comparator output setting:
Off-delay time (OFF-DLY)
Scaling
(A-UNIT)
OUT1 OUT2
Item
Setting detail
Default setting
■ Option Settings
Tolerance mode (LIMITS) DEV
Timing mode (T-MODE) ASYNC
Unit (D-UNIT) mm (UNIT1)
Minimum display unit (D-RES) 0.00005
I/O mode (C-OUT) SUB
Item Setting detail Default setting
