Page 155: Head, Area, Edge number

7-13
Chapter 7 RS-232C
7
■ Numeric Setting Format (
m m m m m m m m
Format)
This format is a fixed length format consisting of a single mark character and seven
numeric characters with no decimal used.
The following format will be used for the corresponding measured value.
Measured value
Format
1.23450
+ 0 1 2 3 4
0
5
Commands in Detail
The following section provides information on commands and responses that the LS-
7000 Series returns when commands are correctly processed. For error responses,
refer to Outline of Command Formats on page 7-6. Refer to Timing Chart on page 7-21
for response delays.
■ Head
This command changes measuring head settings.
LS
Head number
1 : Head 1
2 : Head 2
Command
Response
Area number
1 : AREA 1
2 : AREA 2
Area number
S D
,
H E
,
a
,
b
cr
S D
,
H E
,
a
cr
■ Area
This command changes the area measuring method of the LS-7000 Series.
LS
Area number
1 : AREA 1
2 : AREA 2
Area number
Measuring method
0 : DIA
2 : B-EDGE
1 : T-EDGE
3 : SEG
Command
Response
S D
,
A R
,
a
,
c
cr
S D
,
A R
,
a
cr
■ Edge Number
This command will change the edge number setting in the LS-7000 Series if the area
measurement method is set to SEG.
S D
,
S E
,
a
,
d
d
d
d
e
,
d
d
d
d
e
cr
LS
Edge mode
E : E mode
P : P mode
Edge number
-127~+127
Command
Response
S D
,
S E
,
a
cr
Area number
1 : AREA 1
2 : AREA 2
Area number
