8-3
Chapter 8 Specifications
8
Measuring Head
Model
Measuring range
Minimum detectable object
T-to-R distance
Light source
CCD scanning range
Measurement position accuracy
Repeating accuracy
Sampling times ( ❈7)
Enclosure rating ( ❈8)
Ambient temperature
Relative humidity
Weight
LS-7070
0.5 to 65mm
0.5mm
250±50mm
Approx. 69 mm
±3µm ( ❈5)
±0.2µm ( ❈6)
Transmitter: Approx. 540 g
Receiver: Approx. 730 g
Base: Approx. 660 g
LS-7010
0.04 to 6mm
0.04mm
60±5mm
Approx. 7mm
±0.5µm ( ❈1)
±0.06µm ( ❈2)
Transmitter: Approx. 140 g
Receiver: Approx. 340 g
Base: Approx. 220 g
LS-7030
0.3 to 30mm
0.3mm
160±40mm
GaN green LED
Approx. 33 mm
±2µm ( ❈3)
±0.15µm ( ❈4)
2,400 times/s
IP64
0 to +50˚C (32 to 122˚F)
Transmitter: Approx. 420 g
Receiver: Approx. 470 g
Base: Approx. 430 g
35% to 85% RH, No condensation
❈1: The measuring accuracy is checked with a 1.0-mm-diameter round bar moved within a measuring area
of 2 x 4 mm.
❈2: The repeating accuracy is checked with 1.0-mm-diameter round bar located in the center of the
measuring area to check the outer diameter of the round bar with 512 averaging times and ±2σ set.
❈3: The measuring accuracy is checked with a 10-mm-diameter round bar moved within a measuring area
of 10 x 20 mm.
❈4: The repeating accuracy is checked with 10-mm-diameter round bar located in the center of the
measuring area to check the outer diameter of the round bar with 512 averaging times and ±2σ set.
❈5: The measuring accuracy is checked with a 20-mm-diameter round bar moved within a measuring area
of 20 x 40 mm.
❈6: The repeating accuracy is checked with 20-mm-diameter round bar located in the center of the
measuring area to check the outer diameter of the round bar with 512 averaging times and ±2σ set.
❈7: The number of sampling times per second will be 1,200 when the mutual interference prevention
function is used.
❈8: The Enclosure rating is not applicable to the cable connectors.
Optional Accessories
AC Power Supply Stand
Model
Applicable controller
Weight
Power supply voltage
Power consumption
Operating ambient temperature
Operating ambient humidity
LS-S11
LS-7001
AC100~240V±10% 50/60Hz
110VA max
0 to +40˚C
35% to 85%RH (with no condensation)
Approx.1.7kg
Electrical
rating
Environment
resistance
Extension Cable (Cable between the controller and measuring head)
Model
Cable length
Weight
LS-C3A
3m
Approx. 250 g
LS-C10A
10m
Approx. 700 g
LS-C30A
30m
Approx. 2,000 g
❈ Up to two cables are connectable, provided that the total length is 40 m or less.
TR Cables
Model
Cable length
Weight
OP-42182
1m
Approx. 50g
OP-42183
3m
Approx. 120g
❈ Up to two cables are connectable, provided that the total length is 6 m or less.
