KEYENCE LS-7000 User Manual
Page 123

5-9
Chapter 5 Environment Settings
5
3
Press the
or
key and select the data mode.
The following displayed items can be selected.
None
PLC
Printer 1
Printer 2
GO
GO
GO
GO
4
Press the
ENT
key.
The input item is entered and the RS-232C display appears again.
Note:
Other set values change as shown below according to the selected data
mode.
Only the item OFF is selectable in data transmission mode.
Description
Setting item
NORMAL
The items S1, S2, or S3 is selectable in data transmission mode.
PRINTER1/PRINTER2
The following environment settings are fixed.
Baud rate: 9600
Data length: 8
Stop bit length: 1
Parity: Even
PLC
■ Data Transmission Mode
1
Press the
ENT
key when the RS-232C display is on the screen.
2
Press the
FUNC
key five times.
3
Press the
or
key and select the data transmission mode.
The following displayed items can be selected.
None
S1
S2
S3
GO
GO
GO
GO
4
Press the
ENT
key.
The input item is entered and the RS-232C display appears again.
