4-4
Chapter 4 Function Settings
4
Default Values and Possible Setting Ranges
The following programs settings are made by default.
Items in parentheses indicate what is displayed on the monitor.
■ Area Settings (AREA) (Page 4-7)
Measuring head selection (HEAD No.)
Area (AREA)
Focus monitor (FOCUS)
Area check (A-TEST)
1, 2
Item Possible setting range
Function output setting (FUNCTION)
Edge detection threshold (LEVEL)
Averaging number (AVE)
Difference value
Difference
check (DIFF)
1
DIA
5
OFF
FOCUS
50
1
1000
Default
0 to 9
OFF (No area check), 2 to 127
1, 2, 4, 8, 16
1 to 9999 (in μm, mm, inch, or mil)
Focus monitor (FOCUS),
Area check (A-TEST),
Difference check (DIFF)
10 to 99
Diameter (DIA)
Top edge (T-EDGE)
Bottom edge (B-EDGE)
Segment (SEG)
Specified SEG edge number: -127 to +127
SEG mode: Edge (E) or Pitch (P)
■ Calibration Settings (CALIB) (Page 4-20)
Item Possible setting range Default
Calibration mode (CAL-MODE)
T1-A/T1-B/T2-A/T2-B
THEORY Logic calibration (THEORY),
2-point calibration (2-TARGET),
or 1-point calibration (1-TARGET)
–99.99995 to +99.99995mm ❈
■ Tolerance Settings (LIMIT) (Page 4-50)
-99.99995 to +99.99995mm ❈
Item Default
HH output range (HH)
Threshold
mode
(TOL)
Reference
value mode
(DEV)
+40.00000
HI output range (HI) +30.00000
LO output range (LO) 0.00000
LL output range (LL) -10.00000
HOLD-H OFF
Possible setting range
-99.99995 to +99.99995mm ❈
OFF, -99.99995 to +99.99995mm ❈
OFF, -99.99995 to +99.99995mm ❈
HOLD-L OFF
STANDARD +10.00000
UPPER +1.00000
LOWER -1.00000
HOLD-H OFF
HOLD-L OFF
