5-7
Chapter 5 Environment Settings
5
RS-232C
Take the following steps to make the communication settings for the RS-232C interface and
relative settings for peripheral devices.
Tips
Communication settings for the RS-232C interface vary with the peripheral
device to be connected or the type of output desired. For the details of RS-
232C, refer to Chapter 7 RS-232C on page 7-1.
Setting Items
The following items can be set.
• Baud rate:
Set the speed of data transmission to 1200, 2400, 4800,
9600, 19200, 38400, 57600, or 115200 bps.
• Parity: Set the parity to NONE, EVEN, or ODD.
• Stop bit: Set the stop bit length to 1 or 2.
• Data length: Set the length of transmission data to 7 or 8.
• Data mode: Set the data mode to Normal, PLC, Printer 1 or Printer 2
according to the peripheral device to be connected.
• Data transmission mode: Set the data transmission mode to OFF, S1, S2, or S3.
■ RS-232C Settings
1
Press the
FUNC
key when the program display is on the screen.
■ Baud Rate
1
Press the
ENT
key when the RS-232C display is on the screen.
2
Press the or key and select the baud rate.
3
Press the
ENT
key.
The input item is entered and the RS-232C display appears again.
■ Parity
1
Press the
ENT
key when the RS-232C display is on the screen.
2
Press the
FUNC
key.
