Optional Component Installations—TIGH2U Server
The low-profile riser slot (J5B1) uses a 98-pin connector. It supports up to two low-profile PCIe x4
shows the supported throughput and the number of add-in cards installed for
each possible configuration.
Table 12.
Low-Profile Riser Card Configurations and Throughput
Configuration
Lower Slot
Upper Slot
One add-in card
x4 PCIe
x4 PCIe
Two add-in cards
x4 PCIe
x4 PCIe
Note:
There are no population rules for installing a single low-profile add-in card in the low-
profile riser card slot; a card can be installed in either PCI Express slot. Although the
slots physically accommodate an x8 card, each slot only supports an x4 interface.
See the Intel
®
Server Board S5000PAL Technical Product Specification for the electrical
characteristics for the two PCI-X/PCIe riser card assembly slots.
