TIGH2U Server—Features
Kontron Carrier Grade Server TIGH2U
Product Guide, rev.1.2
December 2009
12
Availability
Two hot-swappable 600 W power supplies in a redundant (1+1) configuration
Disk subsystem configurable as hardware or software RAID
Memory sparing and memory mirroring configurations supported
Manageability
Remote management
Emergency management port (serial and LAN)
IPMI 2.0 compliant
Remote diagnostics support
Optional SMART Embedded USB Solid-State Drive
Optional Intel
®
Remote Management Module 2 (Intel
®
RMM2) providing GCM
support
Upgradeability and
investment protection
Supports up to two Quad-Core Intel
®
Xeon
®
processor 5400 series
†
Multi-generational chassis
Intel
®
64 architecture support
System-level scalability
Supports up to 32 Gbytes FBDIMM memory in non-mirrored mode
Supports up to 16 Gbytes FBDIMM memory in mirrored mode
Supports up to two Quad-Core Intel
®
Xeon
®
processor 5400 series †
Two full-height / full-length x4 PCI Express* (PCIe)* slots
One full-height / full-length 64-bit x 133 MHz PCI-X* slot
Two low-profile / half-length x4 PCI Express slots
Six internal hot-swappable 2.5-nch SAS disk drives
One optical drive (optional)
Front panel
Switches:
• Power switch
• Reset switch
• NMI switch
• ID switch
LEDs / Relays:
• Telco critical alarm fault LED / relay
• Telco major alarm fault LED / relay
• Telco minor alarm fault LED / relay
• Telco power alarm fault LED / relay
• ID LED
• NIC activity LED
• Main power LED
• HDD activity LED
I/O
Front panel:
• Serial B port (RJ45)
• USB 2.0 port
Rear panel:
• Dual PS/2 ports for keyboard and mouse
• Serial B port (RJ45)
• Two USB 2.0 ports
• Intel
®
RMM2 NIC 100 Mbps management
port
• Two RJ45 NIC connectors for 10 / 100 /
1000 Mbps connections
• Video connector
• Alarms connector
Internal connection options Internal connectors/headers:
• One 44-pin ATA/100 connector (power and I/O) for optical drive
• One Intel
®
Remote Management Module 2 (Intel
®
RMM2) connector
• One Intel
®
I/O Expansion Module (optional) supporting either:
- a dual GbE NIC Intel
®
connection
- an external x4 SAS drive
Add-in card support
One full-height riser slot supporting 2U PCI-X and PCIe add-in cards
One low-profile riser slot supporting PCIe add-in cards
† For a list of compatible processors, se
.
Table 1.
Kontron Carrier Grade Server TIGH2U
Features (Continued)
Feature
Description
