Description
Description
A
BIOS Bank Select Jumper
P
CPU Power Connector
B
I/O Module Option Connector
Q
Main Power Connector
C
POST Code Diagnostic LEDs
R
Battery
D
Intel
®
Adaptive Slot – Full-height
S
Power Supply Management Connector
E
PCI Express Riser Slot – Low-profile
T
Dual Port USB 2.0 Header
F
System Identification LED - Blue
U
Serial Port Connector
G
External I/O Connectors
V
SSI 24-pin Control Panel Header
H
Status LED – Green/Amber
W
Intel
®
Remote Management Module 2 (Intel
®
RMM) Connector
I
Serial ‘B’ Port Configuration Jumper
X
System Recovery Jumper Block
J
FBDIMM Sockets
Y
Chassis Intrusion Switch Header
K
CPU #1 Connector
Z
3-pin IPMB Header
L
CPU #2 Connector
AA
Intel
®
Local Control Panel Header
M
Voltage Regulator Heat Sink
BB
Serial ‘A’ Header
N
Bridge Board Connector
CC
Intel
®
RMM2 NIC Connector
O
ATA-100 Optical Drive Connector
(power and I/O)
Note:
In
, connectors shown but not called out are “not used”.
TIGH2U Server—Features
Kontron Carrier Grade Server TIGH2U
Product Guide, rev.1.2
December 2009
20
2.8
Hard Disk Drives
The TIGH2U Server chassis supports up to six 2.5-inch SAS drives in hot-swappable hard drive tray
assemblies at the front of the chassis.
For information on how to install these drives, see
“Installing or Replacing a Hard
Note:
The TIGH2U Server does not support all SAS hard drives. For a list of validated hard
drive manufacturers and hard drive types, see the Tested Hardware and Operating
Systems List (THOL) at
Drives can consume up to 17 W of power each. Drives must be specified to run at a maximum
ambient temperature of 45° C.
