Kontron Carrier Grade Server TIGH2U
December 2009 Product Guide, rev.1.2
15

Features—TIGH2U Server
2.3 Front Panel
Figure 4 shows the front panel of the TIGH2U Server with the bezel installed.
Figure 4. Front View (Bezel Installed)
TS000345
Alarms
Status
ID ON NIC
CRT MNR PWR MJR
A
C B
Item Description Item Description
A Front panel control switches and status LEDs C USB port
B COM port
