77 Publication GMSI00-UM001A-EN-E - February 2005
Chapter
5
Collecting and Reviewing Data
This chapter describes how to collect data with the Enpac Ex. The Enpac Ex
allows you to collect data for points in a list (route) and for unscheduled data
(points not defined in a route). Once you collect your data, you can review the
data on the screen or print it using the RS-232 interface. Then you can unload
into your Emonitor database
Preparing for Data
Collection There are several things you should do before you start collecting data with the
Enpac Ex, assuming you have already loaded at least one list (route) into the
data collector. This section discusses connecting the transducer and setting up
the data collector options.
1. Make sure you have a fully charged battery pack. See Checking Battery
Life on page 14.
2. Check the date and time on the data collector. See Setting the Date,
Time, and Date Format on page 22.
3. Connect the transducer to the Enpac Ex. See Connecting the
Transducer to the Data Collector on page 78.
4. Check the data collection options. See Selecting the Data Collection
Options on page 78.
For information about See page
Preparing for Data Collection 77
Collecting Route Data 79
Collecting Off Route Data 90
Reviewing Data 95
Printing Enpac Ex Screens 98
