Publication GMSI00-UM001A-EN-E - February 2005

Setting Up Measurements 57

Next, find the total collection time for the time waveform measurement
using this formula.

Time synchronous averaging in the Enpac Ex

• Time synchronous averaging cancels out the effects of signals not

related to the synchronizing trigger. Time synchronous mechanical
effects include imbalance, misalignment, eccentricity of bent shafts,
blade passing, and gear meshing.

• Time synchronous averaging requires an external trigger input to the

Enpac Ex.

• Set up a collection specification with the averaging Type set to "Time

Synchronous" and enter the Number of averages. Use a large number
of averages (such as 20 or 30) to get the desired reduction in
non-synchronous effects. For more on supported averaging in the
Enpac Ex, see Number and Type of Averages on page 45.

EXAMPLE

If you had a Maximum frequency value of 7200 CPM and
a Number of lines value of 400, you would:

1. Convert CPM to Hz.

2. Find the total collection time.

WARNING

Do not connect the Enpac Ex to an external trigger unless
the area is known to be nonhazardous.

collection time

spectral lines

Fmax (Hz)

-------------------------------

=

7200 CPM

60

--------------------------

120 Hz

=

400 lines

120 Hz

---------------------

3.3 seconds

=
