Publication GMSI00-UM001A-EN-E - February 2005

Setting Up Measurements 49

• The Enpac Ex may display a phase value that differs from the value that

appears in Emonitor by up to one degree.

• Phase and magnitude measurements at orders require an external trigger

signal.

To set up multiple measurement definitions for magnitude and phase

You create only one measurement definition for magnitude and phase at each
order. The Also collect phase data check box in the Collection
Specification
dialog box determines whether you also want to collect phase as
well as magnitude data.

1. Create a new measurement definition by selecting "Magnitude" in the

Data Type column in the Measurement Definition pane.

2. Select the units for the measurement definition, using a dynamic unit

such as g’s, m/s2, ips, mm/s, mils, um, or V.

3. Select the measurement filter. To collect the magnitude and phase at an

order, select a band filter centered on the order. For example, select
(create if necessary) a first order band filter with a Low cutoff of 0.8
Orders, and a High cutoff of 1.2 Orders. See Measurement Filters on
page 33
for details and the examples on the following pages.

4. Select the collection specification. You must select the Also collect

phase data check box in the Collection Specification dialog box so
the data collector collects phase at orders.

5. Select the storage specification. The first measurement definition is now

complete.

6. If you want to create more than one measurement, copy the

measurement definition by selecting the correct row and selecting Edit
> Copy.

WARNING

Do not connect the Enpac Ex to an external trigger unless
the area is known to be nonhazardous.

IMPORTANT

It is very important that order band filters be centered on
the order. For example, 0.7 to 1.3 orders, 0.8 to 1.2 orders,
0.9 to 1.1 orders, etc. If you do not center the band filters,
magnitude and phase readings may not be accurate.
