63
Publication GMSI00-UM001A-EN-E - February 2005
Chapter
4
Loading and Unloading
This chapter describes using the Enpac Ex with Emonitor to load and unload
lists.
Setting Up for
Communication
This section describes the steps to set up communication both in Emonitor
and in your data collector. The steps include:
• Setting up the computer to communicate with the data collector.
• Selecting the Enpac as the current data collector.
• Setting up the data collector to communicate with the computer.
• Connecting the data collector and the computer.
Many of the steps are completed from the Load/Unload dialog box (Figure
4.1). You use the Set Up Collector button and the Set Up Computer button
to set up the Enpac Ex and computer for communication.
For information about
See page
Loading Lists to the Data Collector
Unloading Lists from the Data Collector
IMPORTANT
For more information about loading lists and the Load /
Unload dialog box, refer to the Emonitor online help.
